HF255 BEATER DRIVE
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
13134-1C10
V-PULLEY, C-BELT, 13 1/2 OD, 1 1/4 B, 1/4 KW
2
1
0-216000
CLIP GUIDE FOR V-BELT, 10 GA * 1 1/2 * 2 3/4
3
1
11050-1510
SPKT 50B15HT, 1 1/4 B, 1/4 KW, 2SS
4
1
0-130217
KEY, 1/4 CD * 4
5
ITEMS 5 & 6 SOLD AS ASSEMBLY
6
6
1710B-1010
BEARING 1 1/4 B, W/BRONZE SLEEVE, RELUBE, 800 SERIES
7
2
28000-0010
SET COLLAR, 1 1/4 BORE, STEEL
8
1
0-260270
SHAFT, JACK TRANSFER, 1 1/4 CRR * 16
9
1
11050-3010
SPKT 50B30, 1 1/4 B, 1/4 KW, 2SS
10
2
0-130201
KEY, 1/4 CD * 1 1/2
11
2
0-260265
SHAFT, BEATER DRIVE, 1 1/4 CRR * 11
12
4
73S00-0718
7/16 * 2 1/4 SPIROL PIN, HBK
13
1
0-260290
BEATER, 18 DIA * 58, 1 1/4 B, 4 ROWS OF TEETH
14
2
0-450015
SHAFT, BEATER IDLER 1 1/4 CRR * 9
15
1
0-260285
SPROCKET, 5040 WITH RATCHET ARM, 1 1/4 B
16
1
17850-0500
ROD END BRG, 5/8-18 THREAD W/ZERK
17
1
12050-1341
CHAIN #50, 134 P, W/CL
18
1
0-260295
BEATER, 18 DIA * 58, 1 1/4 B, 2 ROWS OF TEETH
19
1
11050-1705
CHAIN IDLER #50, 17 T, 5/8 BORE
20
18
72M10-0014
MACHINE BUSHING, 5/8 ID * 1 1/8 OD * 14 GA, ZP
21
1
0-104007
PIVOT ARM, ROLLER CHAIN TIGHTENER
22
1
0-524315
ROLLER CHAIN TIGHTENER ASSY 13 OAL
23
1
37C06-S036
SPRING COMPRESSION, 3/4 ID * 3 3/4 LONG
24
1
0-193155
SPACER TUBE, APRON TIGHTENER, 5/8 OD * 1/2 ID * 1 1/2
25
4
28010-0010
LOCK COLLAR, 1 1/4 BORE, SINGLE SPLIT
