Schuler HF255 - Page 52

- 20 -
FLOOR APRON DRIVE HF295
HF-000130
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
0-260261
SHAFT, FLOOR APRON DRIVE 1 1/2 CRR * 70 1/4 , (3) 3/8 KW
2
1
11060-7212
SPKT 60B72, 1 1/2 B, 3/8 KW, 2SS
3
11
72M24-0014
MACHINE BUSHING, 1 1/2 ID * 2 1/4 OD * 14 GA, ZP
4
2
73E00-0416
1/4 * 2 SPRING PIN, ZP
5
1
0-130218
KEY, 3/8 BRASS * 1 3/4
6
2
16B55-0512
BRG CAST SLEEVE, 1 17/32 B, 4 LONG
7
2
16C25-0612
16B55-0512
8
2
0-130332
KEY, 3/8 CD * 2 1/4
9
1
12060-1372
CHAIN #60, 137 P, W/CL & OL
