Schuler HF255 - Page 61

- 29 -
CROSS CONVEYOR
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
0-260145
CROSS CONVEYOR ASSY, MECHINCAL DRIVE, BOLT-ON
1
0-260230
CROSS CONVEYOR ASSY, HYDRAULIC DRIVE, BOLT-ON
2
2
73S00-0516
5/16 * 2 SPIROL PIN, HBK
3
2
16C10-0608
SPKT CAST, 6T, 1 B, 5/16 PH
4
1
0-260195
CONVEYOR RUBBER SEAL ANGLE 7 GA * 2 1/8 * 59 1/2
5
1
40006-0661
GRAIN SEAL, 3/8 * 6 * 60
6
1
0-260035
CROSS CONVEYOR HOLD DOWN SHOE, LH, 10 GA * 2 3/4 * 67 7/8
7
1
0-260036
CROSS CONVEYOR HOLD DOWN SHOE, RH, 10 GA * 2 3/4 * 67 7/8
8
2
0-260126
BRG PLATE, ADJUSTABLE 10 GA * 6 * 6 3/4
9
REFERENCE CHART PAGE 45
10
0-260110
REFERENCE CHART PAGE 45
11
1
40002-0625
RUBBER SEAL, CLOTH BACKED, 1/8 * 6 * 25 3/4
12
3
0-700049
VM CURTAIN STRAP 7 GA * 1 * 26
13
1
0-260031
RUBBER FLAP ROD ASSY
14
1
40002-2222
RUBBER SEAL, 1/8 * 22 * 11
15
1
0-260021
RUBBER FLAP STRAP, 7 GA * 1 * 22
16
1
0-260129
CROSS CONVEYOR EXT, USED W/FOLD UP EXT
17
1
0-260128
CROSS CONVEYOR EXT, NOT USED W/FOLD UP EXT
18
1
33E00-0212
HYD CYLINDER, 2 * 12, SAE #8 O/R PORTS
19
2
PIN, 1” DIA FOR HYD CYLINDER 33E00-0212
20
2
73H00-0006
HITCH PIN CLIP (HAIR PIN) #6
21
1
33PH1-1141
3/8-3000 PSI * 114, (2) 6FJX SWIVEL
22
1
33PH1-1201
3/8-3000 PSI * 120, (1) 6FJX90 & (1) 6FJX
23
1
0-260040
FLEX YOKE, 6 7/8 HOLE CENTERS, FOR HYD CYLINDER
24
1
0-260155
FOLD UP EXT PIVOT SHAFT ASSY
25
1
0-260177
SHIELD, LOWER PTO
26
1
0-260125
CROSS CONVEYOR SUPPORT ANGLE 7 GA * 2 1/8 * 20 1/2
27
1
73E00-0410
1/4 * 1 1/4 SPRING PIN, ZP
28
1
30101-0800
HAND WINCH 800 LB CAP
29
1
35031-0060
CABLE, 3/16 * 60' LONG
30
1
40002-0325
RUBBER SEAL, 1/8 * 3 1/2 * 25 3/4
31
1
40002-1025
RUBBER SEAL, 1/8 RED BACK * 12 * 25
32
1
0-260138
FOLD UP EXT, 44 OAL, MECHANICAL DRIVE, FRAME WORK ONLY
1
0-260231
FOLD UP EXT, 44 OAL, HYDRAULIC DRIVE, FRAME WORK ONLY
1
0-260142
FOLD UP EXT, 62 OAL, FRAME WORK ONLY
1
0-260232
FOLD UP EXT, 34 OAL, HYDRAULIC DRIVE, FRAME WORK ONLY
33
2
33HT6400-6-8
9/16-18 ORFS TO 3/4-16 O-RING 37^ JIC
34
2
33QPC-4000
PIONEER COUPLER, MALE TIP 3/4 O/R
35
2
17100-2208
BRG INSERT, 1 B, 52MM, 2SS, III LIP SEAL
2
1730P-52MM
FLANGE PLAIN 52MM
2
1730S-52MM
FLANGE W/STRAIGHT ZERK, 52MM
36
2
39011-0000
SHIELD LATCH, LARGE RUBBER
2
39011-0010
RUBBER LATCH HOLDER- U- SHAPE BRACKE
37
1
73S00-0616
3/8 * 2 SPIROL PIN, HBK
38
1
0-971221
SHAFT, CROSS CONVEYOR IDLER 1 CRR * 30 1/2, (2) 5/16 PH
