Technical data
16
04.00 | GWK | Assembly and Operating Manual | en | 389127
3 Technical data
GWK 64 GWK 80 GWK 125
Weight [kg] 0.5 0.65 2.3
Max. payload [kg] 60 86 170
Pneumatic energy transmission 4x M5 and
2x G1/8"
6x M5 and
2x G1/8"
8x G1/8" and
2x G1/4"
Electrical energy transmission 2 x 18 pins 60V/1A
Min./max. distance during locking
[mm]
2
Max. permissible XY axis offset [mm] 1.5
Max. permissible angle offset [°] 1
Repeatability [mm] 0.02
Noise emission [dB(A)] ≤ 70
More technical data are included in the catalog data sheet.
Whichever is the latest version.
