Assembly
04.00 | GWK | Assembly and Operating Manual | en | 389127
17
4 Assembly
4.1 Mechanical connection
Check the evenness
of the bolting surface
The values relate to the entire bolting surface.
Requirements for levelness of the bolting surface (Dimensions in mm)
Diameter Permissible unevenness
< 100 < 0.02
> 100 < 0.05
NOTE
If fitted with inductive proximity switches, these have to be
inserted and mounted before the GWK is mounted.
Options for mounting the GWK:
• Centering shoulder and one cylindrical pin
• Two cylindrical pins
