SCHUNK GWK Series User Manual

Assembly
22
04.00 | GWK | Assembly and Operating Manual | en | 389127
Connector assignment – 18-pin
1 not assigned 11 blue
2 white-yellow 12 red
3 yellow-brown 13 black
4 white-gray 14 purple
5 gray-brown 15 gray-red
6 white-green 16 red-blue
7 brown-green 17 white
8 yellow 18 brown
9 gray 19 green
10 pink
Cable types
18-pin Lapp unitronic FD-D 18x0.14mm²
3-pin Lapp Ölflex 500 P 3x1.5mm²
4-pin Lapp Ölflex 500 P 4x2.5mm²
