SCHUNK PGN-plus Series User Manual

35
Montage- und Betriebsanleitung für
2-Finger-Parallelgreifer Type PGN-plus
Assembly and Operating Manual for
2-Finger Parallel Gripper Type PGN-plus
Anbausatzlisten Mounting kit lists
AS-PGN-plus 64/1 - 64/2 - 80/2 Ident-Nr. / Id. No. 301 630
Pos. / Item Ident-Nr. / Id.-No. Bezeichnung / Description Menge / Quantity
21 5512 276 Schaltnocke / Control Cam 1
26 5512 312 Distanzscheibe / Spacer 1
38 9937 113 Schraube M2 x 14 / Screw M2 x 14 1
AS-PGN-plus 80/1 Ident-Nr. / Id. No. 301 632
Pos. / Item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
21 5512 277 Schaltnocke / Control Cam 1
26 5512 312 Distanzscheibe / Spacer 1
38 9937 352 Schraube M2 x 18 / Screw M2 x 18 1
AS-PGN-plus 100/1 Ident-Nr. / Id. No. 301 634
Pos. / Item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
21 5512 278 Schaltnocke / Control Cam 1
26 5512 312 Distanzscheibe / Spacer 1
38 9937 005 Schraube M3 x 30 / Screw M3 x 30 1
AS-PGN-plus 100/2 Ident-Nr. / Id. No. 301 635
Pos. / Item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
23 5512 279 Schaltnocke / Control Cam 1
26 5512 312 Distanzscheibe / Spacer 1
38 9937 005 Schraube M3 x 30 / Screw M3 x 30 1
AS-PGN-plus 125/1 Ident-Nr. / Id. No. 301 636
Pos. / Item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
21 5512 280 Schaltnocke / Control Cam 1
26 5512 312 Distanzscheibe / Spacer 1
38 9937 005 Schraube M3 x 30 / Screw M3 x 30 1
AS-PGN-plus 125/2 Ident-Nr. / Id. No. 301 637
Pos. / Item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
23 5512 284 Schaltnocke / Control Cam 1
26 5512 312 Distanzscheibe / Spacer 1
38 9960 424 Schraube M3 x 25 / Screw M3 x 25 1
AS-PGN-plus 160/1 Ident-Nr. / Id. No. 301 638
Pos. / Item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
21 5512 281 Schaltnocke / Control Cam 1
26 5512 312 Distanzscheibe / Spacer 1
38 9907 539 Schraube M4 x 40 / Screw M4 x 40 1
AS-PGN-plus 160/2 Ident-Nr. / Id. No. 301 639
Pos. / Item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
23 5512 282 Schaltnocke / Control Cam 1
26 5512 312 Distanzscheibe / Spacer 1
38 9907 483 Schraube M4 x 25 / Screw M4 x 25 1
AS-PGN-plus 200/1 Ident-Nr. / Id. No. 301 640
Pos. / Item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
21 5512 308 Schaltnocke / Control Cam 1
26 5512 312 Distanzscheibe / Spacer 1
38 9907 539 Schraube M4 x 40 / Screw M4 x 40 1
AS-PGN-plus 200/2 Ident-Nr. / Id. No. 301 641
Pos. / Item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
23 5512 309 Schaltnocke / Control Cam 1
26 5512 312 Distanzscheibe / Spacer 1
38 9936 687 Schraube M4 x 30 / Screw M4 x 30 1
Pos. / Item Ident-Nr. / Id. No. Bezeichnung / Description Menge / Quantity
21 5513 854 Schaltnocke / Control Cam 1
26 5512 312 Distanzscheibe / Spacer 1
38 9907 006 Schraube M4 x 45 / Screw M4 x 45 1
AS-PGN-plus 240/1 Ident-Nr. / Id. No. 301 643
Air-Oil Systems, Inc. www.airoil.com

SCHUNK PGN-plus Series Specifications

General

Material	Aluminum, steel
Gripper Type	Parallel Gripper
Repeatability	±0.01 mm
Operating Pressure	2 to 8 bar
Opening Time	0.1-0.5 s
Ambient Temperature	5 °C
