Scope of delivery
16
02.00|ROTA NC plus 2 / ROTA NCF plus 2 |en
Warranty
If the product is used as intended, the warranty is valid for 24
months from the ex-works delivery date under the following
conditions:
• Observe the applicable documents, ( 1.2, Page 6)
• Observe the ambient conditions and operating conditions
• Observe the maximum number of clamping cycles
( 6, Page 17)
• Observe the specified maintenance and lubrication intervals,
( 9, Page 38)
Parts touching the workpiece and wear parts are not included in
the warranty.
Torques per screw
Tightening torques for mounting screws used to clamp the chuck
on lathes or other suitable technical equipment (screw quality
10.9)
Screw size
M6
M8
M10
M12
M14
M16
M18
M20
M22
M24
M27
M30
Admissible torque
M
A
(Nm)
13
28
50
88
120
160
200
290
400
500
1050
1500
Tightening torques for mounting screws used to attach top jaws
onto the chuck (screw quality 12.9)
Screw size
M6
M8
M10
M12
M14
M16
M20
M24
Max. admissible torque M
A
(Nm)
16
30
50
70
130
150
220
450
Tightening torques for the protection sleeve mounting screws
(screw quality 8.8)
Screw size
M3
M4
M5
M6
Tightening torques M
A
(Nm)
1.3
3.0
5.5
9.0
Scope of delivery
1
Power chuck
3
Mounting screws
6
T-nuts with screws or 3 combi T-nuts
1
Mounting wrench (from size 260 and up)
1
Eye boltfrom size 260 and up
1
Operating manual
3
4
5
