Spare parts
40
02.00|ROTA NC plus 2 / ROTA NCF plus 2 |en
Disposal
After decommissioning, place the chuck in a position that enables
any liquids in the chuck to drain out.
• Collect the escaping liquids and dispose of them properly in line
with the statutory provisions.
• Remove any identifiable plastic or aluminum parts installed in
or on the chuck and dispose of them properly in line with the
statutory provisions.
• Dispose of the chuck's metal parts as scrap metal.
Alternatively, you can return the chuck to SCHUNK for proper
disposal.
Spare parts
When ordering spare parts, it is imperative to specify the type,
size and above all the manufacturing no of the chuck.
Seals, sealing elements, screw connections, springs, bearings,
screws and wiper bars plus parts coming into contact with the
workpiece are not covered by the warranty.
Item
Designation
Quantity
1
Chuck body
1
2
Base jaws
3
3
Piston
1
4
Center sleeve
1
5
Draw nut **
1
6
Mounting ring **
1
7
Mount
1
9
Compensating weight *
3
10
Lever *
3
11
Locking pin
3
12
Valve piston
6
13
Set screw *
6
15
Set screw *
6
16
Set screw *
6
17
Compression spring *
6
18
Steel ball *
6
19
Seal *
6
20
Seal *
6
10
11
