SCHUNK ROTA NC plus 2 Series User Manual

FB155_enM / Änderungsstand 02/03.12.2013
Translation of the original declaration of incorperation
in terms of the Directive 2006/42/EG, Annex II, Part 1.B of the European Parliament and of the
Council on machinery
Manufacturer
H.-D. SCHUNK GmbH & Co. Spanntechnik KG.
Lothringer Str. 23
D-88512 Mengen
We hereby declare that on the date of the declaration the following incomplete machine
complied with all basic safety and health regulations found in the directive 2006/42/EC of the
European Parliament and of the Council on machinery. The declaration is rendered invalid if
modifications are made to the product.
Product designation:
Typen designation:
ID-number:
Power Lathe Chucks with Through-hole (centrifugal force
compensation)
NCF plus 2 / NC plus 2 in sizes 185-52; 215-66; 260-86; 315-104
0854106; 0854107; 0854108; 0854109; 0854116; 0854117; 0854118;
0854119; 0854126; 0854127; 0854128; 0854129; 0854136; 0854137;
0854138; 0854139; 0852106; 0852107; 0852108; 0852109; 0852116;
0852117; 0852118; 0852119; 0852126; 0852127; 0852128; 0852129;
0852136; 0852137; 0852138; 0852139.
The incomplete machine may not be put into operation until conformity of the machine into
which the incomplete machine is to be installed with the provisions of the Machinery Di-
rective (2006/42/EC) is confirmed.
Applied harmonized standards, especially:
DIN EN ISO 12100:2010
Safety of machinery – General principles for design – Risk assessment and
risk reduction
DIN EN 1550:1997
+A1:2008
Machine-tools safety – Safety requirements for the design and
construction of work holding chucks
Other related technical standards and specifications:
DIN ISO 702-1:2009
Machine tools – Connecting dimensions of spindle noses and work holding
chucks – Part 1: Conical connection
DIN ISO 702-4:2004
Machine tools – Connecting dimensions of spindle noses and work holding
chucks – Part 2: Cylindrical connection
VDI 3106:2004-04
Determination of permissible speed (rpm) of lathe chucks (jaw chucks)
The manufacturer agrees to forward on demand the relevant technical documentation for the
partly completed machinery to state offices.
The special technical documents according to Appendix VII, Part B belonging to the incom-
plete machine have been compiled.
Person authorized to compile the technical documentation:
Philipp Schräder, Address: see manufacturer's address
p.p.
Mengen, December 2013
Philipp Schräder, Head of development
