SCHUNK ROTA NC plus 2 Series User Manual

Technical data
02.00|ROTA NC plus 2 / ROTA NCF plus 2 |en
17
Technical data
Chuck data
ROTA NC plus 2
ROTA NCF plus 2
Size
185
215
260
315
185
215
260
315
Max. actuating force
[kN]
30
42
60
70
30
42
60
70
Max. clamping force
[kN]
72
100
140
160
72
100
140
160
Max. speed [rpm]
5000
5000
4000
3500
6000
6000
4500
4000
Stroke per jaw [mm]
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
Piston stroke [mm]
20
20
20
20
20
20
20
20
Chuck through bore
[mm]
52
66
86
104
52
66
86
104
Weight [kg]
15.2
20.3
33.3
49
14.3
19.7
32
48.4
Centrifugal force of a
base jaw M
cGB
[kgm]
0.029
0.041
0.087
0.155
– 0.011*
– 0.03*
– 0.04*
– 0.094*
Max. jaw eccentricity
of center of gravity in
axial direction a
max
[mm]
24
40
40
40
24
40
40
40
Operating
temperature
15 – 60°C
* with centrifugal force compensation taken into account
The specified maximum speed of rotation stated only applies when
using the maximum clamping force and the SHB-type, hard,
standard stepped jaws that go with the chuck.
The maximum permissible speed of rotation for the specific
machining has to be defined by the user on the basis of the
required clamping forces. This speed must not exceed the
maximum speed of rotation of the chuck.
Warranty and maximum clamping cycles
Length of warranty
24 Months
Maximum clamping cycle number
500 000 Cycles
Ensure minimal weight for all jaws.
For unhardened top jaws or chuck jaws in special design, the
permissible RPM according to VDI 3106 must be calculated for the
respective machining job. Whereby the recommended maximum
speed must not be exceeded. The values calculated must be
checked by means of dynamic measurement using a clamping
force tester.
6
6.1

SCHUNK ROTA NC plus 2 Series Specifications

General
