SCHUNK ROTA NC plus 2 Series User Manual

Spare parts
02.00|ROTA NC plus 2 / ROTA NCF plus 2 |en
41
Item
Designation
Quantity
21
Compression spring *
6
22
Compression spring *
6
23
Steel ball *
6
24
Seal *
6
25
Set screw *
3
25
Set screw ***
6
26
Compression spring **
2
27
Steel ball **
2
28
Screws
3
29
Screws
6
30
Screws
3
31
O-ring
1
33
Conical lubrication nipple
3
35
O-ring
1
36
Support ring
1
37
O-ring
1
38
O-ring
1
39
Seal
3
41
Compression spring *
6
42
Compression spring *
6
43
Lever for assembly key
1
44
Eye bolt **
1
45
Assembly key **
1
46
T-nuts (1/16" x 90°)
6
46
T-nuts (1.5 x 60°)
3
*
only for NCF plus 2
**
only for chuck size 260 - 315
***
only for NC plus 2
