Function and handling
02.00|ROTA NC plus 2 / ROTA NCF plus 2 |en
37
• Remove the piston (Item 3) from the chuck body (Item 1).
• Push the base jaws (Item 2) with the seal (Item 39) inward out
of the base jaw guide.
Degrease and clean all parts and check for damage and wear.
Replace damaged parts only with original SCHUNK replacement
parts.
Prior to assembly, replace all seals and thoroughly grease all parts
with LINO MAX special grease. The sealing kit is available from
SCHUNK.
CAUTION
Allergic reactions due to grease in contact with skin!
Wear gloves.
Assemble the chuck in reverse order.
During assembly, special care must be taken that the numbers of
the base jaws are identical to the numbers of the corresponding
jaw guide. The seal (Item 39) of the base jaw must not be
damaged during assembly.
A compensating weight (ROTA NCF plus 2 only - Item 9) contains a
total of 4 check valves.
For the correct setting of the valves, screw in the set screw (Item
13, 16) until flush.
In the case of the NCF plus 2-215 and NCF plus 2-260, screw in the
set screw (Item 13) to the stop and then unscrew one revolution.
