ROTA EP
Size
380-127
460-165
460-185
500-260
460-165-
LH
460-185-
LH
Chuck Ø
380
460
460
500
460
460
Chuck through bore [mm]
127
165
185
26
165
185
Max. clamping force [kN]
160
230
230
80
230
220
Max. rotation speed
[min-1]
2300
1600
1600
1000
1600
1600
Stroke per jaw [mm]
7
7
7
15
19
19
Serration of the jaws
[mm]
3/32" x 90°
1/16" x
90°
3/32" x 90°
Distributor ring Ø [mm]
380
460
460
467
460
460
Centrifugal torque of
base jaw [kgm] M
cGB
0.432
0.622
0.640
0.343
0.787
0.816
Max. jaw eccentricity of
center of gravity in axial
direction [mm] a
max
36
32
36
40
The specified maximum speed of rotation stated only applies when
using the maximum clamping force and the SHB-type, hard,
standard stepped jaws that go with the chuck.
WARNING
Risk of personal injury and property damage due to parts flying
off in the event of a screw breakage on unhardened top jaws!
Soft standard top jaws must be hardened in the countersink
region.
They should only be depth-hardened, not surface-hardened.
If unhardened top jaws or chuck jaws in a special design are used,
ensure that the jaws weigh as little as possible. For soft top jaws or
chuck jaws in special design, the permissible speed of rotation
according to VDI 3106 must be calculated for the machining job in
question. The recommended maximum speed must not be
exceeded. The calculations must be checked using dynamic
measurement. Function monitoring (piston movement and
actuating pressure) must be performed in accordance with the
guidelines of the Berufsgenossenschaft (employers' mutual
insurance association).
Warranty and maximum clamping cycles
Duration of warranty
24 Months
Maximum clamping cycles
500 000
