Scope of delivery
16 02.00|0889073_ROTA TB-TBS-EP |en
Warranty
If the product is used as intended, the warranty is valid for 24
months from the ex-works delivery date under the following
conditions:
• Observe the applicable documents, ( 1.2, Page 6)
• Observe the ambient conditions and operating conditions
• Observe the maximum number of clamping cycles
( 6.1, Page 19)
• Observe the specified maintenance and lubrication intervals,
( 9, Page 48)
Parts touching the workpiece and wear parts are not included in
the warranty.
Torques per screw
Tightening torques for mounting screws used to clamp the chuck
on lathes or other suitable technical equipment (screw quality
10.9)
Screw size
M6
M8
M10
M12
M14
M16
M18
M20
M22
M24
M27
M30
Admissible torque
M
A
(Nm)
13
28
50
88
120
160
200
290
400
500
1050
1500
Tightening torques for mounting screws used to attach top jaws
onto the chuck (screw quality 12.9)
Screw size
M6
M8
M10
M12
M14
M16
M20
M24
Max. admissible torque M
A
(Nm)
16
30
50
70
130
150
220
450
Scope of delivery
1
ROTA TB chuck
6
T-Nuts
2
Elbow connectors
2
Straight connectors
1
Eye bolt
Mounting screws
1
Operating manual
3
4
5
