SCHUNK ROTA TB 630-310 - Spare Parts

Spare parts
62 02.00|0889073_ROTA TB-TBS-EP |en
Spare parts
When ordering spare parts, it is imperative to specify the type,
size and above all the manufacturing no of the chuck.
Seals, sealing elements, screw connections, springs, bearings,
screws and wiper bars plus parts coming into contact with the
workpiece are not covered by the warranty.
Spare parts list for all TB 400 – 850 and TB-LH 400 – 850
Item
Designation
1
Chuck body
2
base jaw
3
Piston
4
Sleeve
5
Sealing disk
6
Piston cover
7
Cylinder mount
8
Distributor ring
9
T-nuts
13
double check valve
15
Locking screw
16
Filler plug
19
Screw DIN EN ISO 4762/10.9
20
Screw DIN 7984 / 10.9
21
Screw DIN 7984 / 10.9
23
Screw DIN EN ISO 4762 / 10.9
24
Screw DIN EN ISO 4762 / 10.9
25
Screw DIN EN ISO 4762/10.9
26
funnel lubrication nipple
37
O-ring DIN 3771
39
O-ring DIN 3771
40
O-ring DIN 3771
41
O-ring DIN 3771
42
O-ring DIN 3771
43
O-ring DIN 3771
44
O-ring DIN 3771
45
O-ring DIN 3771
47
Profile seal
52
Straight screw connection
53
Swivel fitting
54
Fiber sealing
