Appendix on Declaration of Incorporation, as per
2006/42/EC, annex II, No. 1 B
1. Description of the basic safety and health protection requirements, as per 2006/42/EC,
annex I, that apply to and are fulfilled for the scope of the partly completed machine:
Product designation
ROTA TB/TB-LH/TBS/TBS-LH/EP/EP-LH pneumatic chuck
Type designation
ROTA TB 400-115; 400-140; 470-185; 500-160; 500-205; 500-230; 600-275; 610-260; 630-265; 630-
310; 630-325; 630-330; 800-365; 800-375; 800-395; 800-410; 1000-534. ROTA TB-LH 400-140; 470-
185; 500-205; 500-230; 600-275; 610-260; 630-265; 630-275; 630-325; 850-375; 1000-560; 1200-
640. ROTA TB-LH-LC 850-375. ROTA EP 380-127; 460-165; 460-185; 500-260. ROTA EP-LH 460-165;
460-185; 500-260; 610-265.
ID number
0818001; 0818002; 0818011; 0818012; 0818050; 0818122; 0818131; 0818017; 0818032; 0818040;
0818041; 0818240; 0818005; 0818004; 0818015; 0818016; 0818019; 0818051; 0818125; 0818026;
0818135; 0818141; 0818014; 0818035; 0818003; 0818006; 0818007; 0818052; 0818008; 0818009;
0818023; 0818018
To be provided by the System Integrator for the overall machine
⇓
Fulfilled for the scope of the partly completed machine
⇓
Not relevant
⇓
1.1
Essential Requirements
1.1.1
Definitions
X
1.1.2
Principles of safety integration
X
1.1.3
Materials and products
X
1.1.4
Lighting
X
1.1.5
Design of machinery to facilitate its handling
X
1.1.6
Ergonomics
X
1.1.7
Operating positions
X
1.1.8
Seating
X
1.2
Control Systems
1.2.1
Safety and reliability of control systems
X
1.2.2
Control devices
X
1.2.3
Starting
X
1.2.4
Stopping
X
1.2.4.1
Normal stop
X
1.2.4.2
Operational stop
X
1.2.4.3
Emergency stop
X
1.2.4.4
Assembly of machinery
X
1.2.5
Selection of control or operating modes
X
1.2.6
Failure of the power supply
X
1.3
Protection against mechanical hazards
1.3.1
Risk of loss of stability
X
1.3.2
Risk of break-up during operation
X
1.3.3
Risks due to falling or ejected objects
X
1.3.4
Risks due to surfaces, edges or angles
X
1.3.5
Risks related to combined machinery
X
1.3.6
Risks related to variations in operating conditions
X
1.3.7
Risks related to moving parts
X
1.3.8
Choice of protection against risks arising from moving parts
X
1.3.8.1
Moving transmission parts
X
1.3.8.2
Moving parts involved in the process
X
1.3.9
Risks of uncontrolled movements
X
