02.00|0889073_ROTA TB-TBS-
41
cylindrical recess on the mount (depth 8 mm) - i.e. only screwed in
only 7 mm deep - to ensure that it touches the outer edge of the
chuck. SCHUNK provides standard flanges that can be used to
mount the pneumatic chuck on spindles in accordance with DIN
55026, DIN 55027 and DIN 55029.
TB and TB-LH 400 ā 850
Pilot-controlled check valve
