43
1
Distributor ring
11
Locking screw
2
Profile gap 1.5 mm
12
Pilot-controlled check valve
3
Lubricating nipple
13
Piston cover
4
O-rings
14
Chuck body
5
Sealing disk
15
O-rings
6
Screw (for mounting chuck body on
cylinder)
16
Pneumatic connection
7
Cylindrical screw with hexagon socket
17
Cylinder
8
T-nut
18
Screw for mounting cylinder on flange
or spindle
9
Guide bushing
19
DIN 908 locking screw and copper seal
10
Piston
20
Profile seal
In order to prevent the chuck from being subjected to greater
loads, the centering mount can be replaced with one that has a
short taper and is suitable for direct mounting on the spindle nose
using a bayonet (DIN 55027) or Camlock (DIN 55029). The inner
and outer O-rings that are used for static sealing must be taken
into account if doing this. The guide bushing can only be mounted
with screws once this is done.
