Schwank ThermoControl Plus M2 User Manual

- 4 -
2 Your Safety
Installation details
Danger!
Note that electric shocks can be
highly dangerous. Pay attention while
working on electrical equipment. The
electrical installation must be carried
out by a qualified engineer to the
current national and international
standards. Check the electrical
equipment regularly. Defective wires
etc. must be replaced immediately.
The appliance must be isolated from
power supply before working with
the electrics. Make sure that nobody
can connect appliance to the power
supply while you are working.
.
The Schwank ThermoControl Plus 2
has to be mounted on/at a place,
where it’s not affected by vibrations
or shocks.
The feed/supply line has to be
protected by a fuse with max. 16 A
on the part of the builder.
Please install the ThermoControl
Plus M2 ensuring conformity to the
wiring diagram, which is located in
the switchboard.
Ensure that the controller and
consumer are connected by a 1.5
mm
2
cable, further on controller and
sensor have to be connected by a
telephone cable.
Install the room-temperature-
sensor between the radiation
area of two heaters at a height of
2.5 m. Therefore the controller
receives an optimal value of the
nominal temperature.
+ If the controller is installed in a
large sized building or in a building
with extreme temperature
differences (temperature gradiants),
you can also average over, instead
of using room-temperature-sensors
for every single control circuit.
Settins and modification of the
function parameters can be carried
out only by Schwank service
technicians.
