Date Code 20210715 SEL-2890 Instruction Manual
Settings and Commands
Settings
3.3
ROUTE_IP1
d,e
Routing destination 1
address
IP address
a
192.168.0.3
HEADER1
d,e
Routing destination 1
message header
As many as 8 bytes
entered in
hexadecimal
A5
ROUTE_PORT2 Routing destination port 2 1026–65535,
0 disables
8002
ACCEPT2
d
Accept routing connection Y, N N
ROUTE_IP2
d,e
Routing destination 2
address
IP address
a
192.168.0.3
HEADER2
d,e
Routing destination 2
message header
As many as 8 bytes
entered in
hexadecimal
A5
ROUTE_PORT3
d
Routing destination port 3 1026-65535,
0 disables
0
ACCEPT3
d
Accept routing connection Y, N N
ROUTE_IP3
d,e
Routing destination 3
address
IP address
a
192.168.0.3
HEADER3
d,e
Routing destination 3
message header
As many as 8 bytes
entered in
hexadecimal
Empty
c
Serial Port Settings
SPEED Serial port data rate (bps) 300, 600, 1200,
2400, 4800, 9600,
19200, 38400,
57600, 115200
19200
STOP
f
Stop bits 1, 2 1
PARITY
f
Parity bit value (hidden
and forced to None if
BITS+STOP=10)
Odd, Even, None None
FLOW Serial flow control mode Hardware, Soft-
ware, None
None
RTS_LOW Force RTS line low
(available only if
FLOW=NONE)
Y, N N
IP
g
IP address of SEL-2890 IP address
a
192.168.0.2
Table 3.1 SEL-2890 Settings Summary (Sheet 3 of 4)
Setting Name Description Range
Default
Value
