Schwing FW 18 - Page 27

Service Manual
Remote Control Cable/Radio
579
Fig. 1
Fig 2.
LEDs
NG
UF
UE 1
UCC 1
UE 2
UCC 2
NOT 1
HF
K1
K2
MC 2
MC 1
ST 1
ST 2
REL
PROP
TEL
TST3
TST2
TST1
= proportional control receiver
= black and white control receiver
= power supply
= vehicle system voltage
= controller 1 supply
= controller 1 supply (+5V)
= controller 2 supply
= controller 2 supply (+5V)
= failure in EMERGENCY SHUT-OFF
circuit of controller 1
= receiver
= RF-channel 1 selected
= RF-channel 1 selected
= controller 2 data message reception
= controller 1
= controller 1 failure
= controller 2 failure
= relay output defective
= proportional control output defective
= data message reception
= data message error 3
= data message error 2
= data message error 1
fig. 1
fig. 2
