Service Manual
Remote Control Cable/Radio
583
The following operating state must now be dis-
played at the receiver:
The unit is now ready for operation.
In case of trouble, cf. section 15.
MODULE LED DISPLAY
NG NOT1 + NOT2
off (EMERGENCY SHUT-OFF circuit
closed)
HF K1 or K2
permanently lit (depending on transmitter
channel selection)
MC 2 MC 2
flashing regularly (data message transmis-
sion rate)
MC 1 TEL flashing regularly, all others off
REL REL
flashing regularly (only for black-and-
white control)
