Schwinn 145 - Console Installation Steps; Install Console on Console Mast

12
9. Install Console on Console Mast
Note: Remove the pre-installed screws from the back of the Console before you connect the cables.
NOTICE: Do not crimp the cables.
11
X4
11
X4
