Schwinn 145 - Assembly

7
1. Install Stabilizers to Frame
Note:MakesuretheSchwinn®decalontheRearStabilizerfacesoutwardfromthemachine.
2. Attach Pedals to Frame Assembly
Note: The Left Pedal is reverse-threaded. Be sure to attach Pedals on the proper side of the Bike. Orientation is
based from a seated position on the bike. The Left Pedal has an “L”, the Right Pedal an “R”.
4
5
1
3
X4
L
14
13
2
X2
M
ASSEMBLY
