Schwinn 145 - Parts; Tools

5
pARTS / TOOLS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Tools
Included Not Included
6 mm
(recommended)
Item Qty Description Item Qty Description
1 1 Main Frame 9 1 Handlebar
2 1 Front Stabilizer 10 1 Console Bracket
3 1 Rear Stabilizer 11 1 Console
4 1 Pedal, Left 12 1 AC Adapter
5 1 Pedal, Right 13 1 End Cap, Right
6 1 Seat Post 14 1 End Cap, Left
7 1 Seat 15 1 Water Bottle Holder
8 1 Console Mast
Note:MediaCableisintheConsolebox.
