Schwinn 145 - Page 8

8
3. Loosen and Pull the Seat Post Adjustment Knob to Attach Seat Post to Frame Assembly
NOTICE: TheAdjustmentKnobispre-installedontheMainFrame.MakesuretheAdjustmentKnobengages
the Seat Post.
!
Do not set the Seat Post position higher than the stop mark (MAX) on the tube.
4. Attach Seat to Frame Assembly
6
7
