9
5. Connect Console Mast Cable to Frame Assembly Cable
NOTICE: Align the clips on the cable connectors and make sure the connectors lock. Do not crimp Console Cable.
6. Attach Console Mast to Frame Assembly
NOTICE: Do not crimp the cables.
8
F
X4
I
