ASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
Parts
#2 Console (Qty 1)
#3 Fan Assembly (Qty 1)
#18 Console Mast (Qty 1)
#19 Static Handlebar (Qty 1)
Hardware
#11 5x8 Pan Head Screw (Qty 4)
Step 4—Attach the Console to the Console Mast
4–1 Attach the Console/Fan/Static
Handlebar Assembly (#2, #3,
and #19) to the Console Mast
(#18) with four (4) Pan Head
Screws (#11).
Figure A–4
19
2
3
18
11
