Schwinn 438 - Attach the Lower Handlebar Assemblies

14
ASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
Parts
#6 Lower Left Handlebar Assembly
(Qty 1)
#7 Left Pedal Arm Assembly
(Qty 1)
#8 Left Upper Handlebar (Qty 1)
#9 Lower Handlebar Cover Set
(Qty 2)
#10 Lower Right Handlebar
Assembly (Qty 1)
#15 Right Pedal Arm Assembly
(Qty 1)
#16 Right Upper Handlebar
(Qty 1)
Hardware
#29 Nylon Hex Nut (Qty 2)
#30 8x10 Set Screw (Qty 4)
#37 8x50 Carriage Bolt (Qty 2)
#41 4x16 Self-Tapping Round Head
Screw (Qty 4)
Step 9—Attach the Lower Handlebar Assemblies
9–1 Attach the Lower Right
Handlebar Assembly (#10) to
the Right Upper Handlebar
(#16) using the two (2) Set
Screws (#30).
9–2 Attach the Lower Right
Handlebar (#10) to the Right
Pedal Arm Assembly (#15)
using a Nylon Hex Nut (#29),
and a Carriage Bolt (#37).
9–3 Secure the Lower Handlebar
Cover Set (#9) to the Lower
Right Handlebar Assembly
(#10) with two (2) Self-Tapping
Round Head Screws (#41).
9–4 Repeat steps 9–1 through 9–3
for the Lower Left Handlebar
Assembly (#6).
