23
X8
A
6mm
12. Connect the Cables. While Inserting the Upper Handlebar, Gently Pull the Cable Down into
the Lower Handlebar, and Attach the Upper Handlebar.
In order to avoid possible serious injury when inserting the tube ends onto the Lower Handlebars, be
careful to avoid ngers or hands being caught or pinched.
Some components of the machine can be heavy or awkward. Use a second person when doing the assembly
step involving these parts. Do not do steps that involve heavy lifting or awkward movements on your own.
Note: Do not pinch or cut the Cables. When the Upper Handlebars are attached, push the exposed cables back into the
Upper Handlebars as far as possible without damaging them. A decal has been applied to all right (“ R ”) and left
(“ L ”) parts to assist with assembly.
“ Resistance “
“ Incline “
To Next Page
