Schwinn 590e - Page 24

24
13. Attach the Interior Handlebar Covers, and then Snap the Exterior Handlebar Covers to the
Frame Assembly
Note: Do not pinch or cut the Cables inside the Handlebars. Before installing hardware, inspect to be sure that the hard-
ware will not cut any of the cables inside the Handlebars. If necessary, adjust the cables and inspect again.
X4
D
3
3
4
4
#2
