The solenoid  fuse (8) and a spare fuse (9) are
located on the solenoid  (C). Remove the fuse
caps (D) to reach them.
Solenoid  fuse key
Pos El. item Rat.
8 Solenoid  fuse 30 A
9 Spare 30 A
To access the main fuse (10), pull its box out of the
housing (E) and remove the protective cap (F).
Main fuse box key
Pos El. item Rat.
10 Main fuse 30 A
8
C
D
9
Fig 189
10
F
E
Fig 190
