EQUIPMENT
NOTE: Illustrations may not be accurate for every model and are only provided as
a visual guide.
3 2 41
9
8
11
8
5 5 10
7
6
smo2011-003-003_b
TYPICAL - WAKE MODEL ILLUSTRATED
1) Glove Box
A small, storage compartment for per-
sonal articles.
Pull up on cover latch to open glove
box.
smo2009-002-120_a
TYPICAL — GLOVE BOX
1. Cover latch
2) Front Storage
Compartment
A convenient area to carry personal ar-
ticles.
The front storage compartment also
contains two holders for safety
equip-
ment; one for a fire extinguisher and
another for the emergency kit (these
are not provided).
smo2011-003-011_b
FRONT STORAGE COMPARTMENT
1. Fire extinguisher secured in holder
2. Emergency kit secured in holder
To open the front storage compart-
ment cover, pull the latch lever upward
Always close and latch cover when rid-
ing.
