EQUIPMENT
NOTICE
Ensure drain plugs are
properly secured prior to launching
the watercraft in water.
9) Ski/Wakeboard Post
WAKE Model
Pullupontheknobtoextendthepost.
Ensure both sections of post are fully
extended and properly locked before
attaching ski or wakeboard rope.
smo2011-003-015_a
TYPICAL - SKI/WAKEBOARD POST
RETACTED
1. Pull on this knob to extend
smo2011-003-016
TYPICAL - SKI/WAKEBOARD POST
EXTENDED
To retract the post, push straight down
on the top of the post.
If the post becomes difficult to extend
or retract, simultaneously push in on
both sides of the locking clip toward
front of watercraft.
smo2011-003-017_a
TYPICAL - PUSH TOWARD FRONT TO
UNLOCK AND REMOVE POST
1. Locking clip
WARNING
Make sure ski/wakeboard post is
fully extended and locked before
use. Completely retract and lock
when not used. Use caution with
skier/wakeboarder in tow as tow
rope may backlash to watercraft
when released. Never perform a
sharp turn when towing a skier,
wakeboarder or any toy.
NOTICE
The ski/wakeboard post is
designed for towing a skier or wake-
boarder with a maximum gross
weight of 114 kg (250 lb).
Always have one person other than the
operator as an observer.
NOTE: The handles on the ski/
wakeboard post are provided as a
handhold for the observer.
NOTICE
Never use the ski/
wakeboard post to tow other water-
craft. Respect the maximum load
limit rating of the ski/wakeboard
post. Overloading can affect ma-
neuverability, stability and perfor-
mance.
10) Wakeboard Rack
WAKE Model
A convenient removable rack to carry a
wakeboard on the watercraft when on
the water.
_______________
69
