GENERAL OPERATIONS
1
TECHNICAL SPECIFICATIONS
DIMENSIONS
:
3.9” H x 10.5” W x 10.9” D
99mm H x 265mm W x 278mm D
WEIGHT
:
10 Lbs.
4.5 Kgs.
ELECTRICAL
:
Type Acceptance FCC Parts 80, 87, 90
FCC Identifier BZ6SEA235
Frequency Range (TX) 1.605 - 29.999 MHz
(RX) 0.490 - 29.999 MHz
Operating Temperature -30 degrees to +60 degrees C
Frequency Stability
± 10 Hz
Operating Modes J3E, R3E, H3E (2182 KHz)
A1A (CW), F2B (TELEX)
Primary Voltage 13.6 V DC ± 15% (11.6 - 15.6 V DC)
Negative Rail Common to Chassis
Current Drain Receive Standby 1 Amp
Receive Full Audio 1.5 Amps
Transmit Voice 11 Amps
Transmit Two-Tone 17 Amps
Transmit TELEX 22 Amps
Output Impedance 50 ohms
Transmitter Output Power R3E, J3E 150 Watts PEP
F2B 150 Watts
LOW 50 - 75 Watts
VLOW 25 - 40 Watts
Receiver Sensitivity
≤ 1 µV for 12 dB SINAD
Audio Output
4 W @ ≤ 10% distortion into external
4 ohm load.
