| Page 29 | SEABOB Operation Manual | 5
To charge the accumulator box, proceed as fol-
lows:
1. Place the SEABOB and accumulator box on a sturdy
and dry surface that will not damage the compo
-
nents.
2. Dry the area around the charging socket using a soft,
clean cloth.
3. Remove the sealing cap from the charging socket,
and check that the inside of the charging socket is
perfectly clean and dry.
4. Remove the sealing cap from the charging plug, and
check that the charging plug is clean and dry. Never
attempt to remove the sealing cap by twisting or
pulling on the charging cable. Always hold on to the
locking ring of the charging plug when removing the
sealing cap.
5. Ensure that the charging plug of the charger is po
-
sitioned correctly (the red dot on the charging plug
should be pointing to the bow of the SEABOB) before
plugging it into the charging socket of the accumula
-
tor box.
6. Only after this has been done should you plug the
mains plug of the charger into the mains socket.
Follow the technical specifications of the charger,
particularly with regards to the correct input volt
-
age (see "Data Sheet for Charger" and "Instructions for
Use of the Quick Charger").
If using the charger in other countries only use
travel plugs which are approved for currents of
at least 10 A.
7. The charge display will appear in the SEABOB’s dis
-
play after 15 seconds (system check). The device is
now in Charge mode. Select the desired charging
process. For partial charging (for air transport / stor
-
age), tap the green button on the right Controlgrip.
A partially filled charge symbol will appear in the up
-
per left-hand part of the display with an arrow to
indicate partial charging. For full charging (for op
-
eration), tap the red button on the left Controlgrip.
A completely filled charge symbol will appear with
an arrow to indicate full charging.
