8.4 Function Setting
The ending mark of command is “<CR><LF>”.
Command Function
Command & Feedback
Example
#SET_RS232_BAUD
[PARAM]
Set the RS232 baud rate.
[PARAM]=1 ~ 7
1 - 115200
2 - 57600
3 - 38400
4 - 19200
5 - 9600
6 - 4800
7 - 2400
#SET_RS232_BAUD 0
@RS232_BAUD 5
#GET_RS232_BAUD Get the RS232 baud rate
#GET_RS232_BAUD
@RS232_BAUD 5
#SET_OUTPUT_RES
[PARAM]
Set the output resolution.
[PARAM]= 1 ~ 8
1 - 1024x768 60 HZ
2 - 1280x720 60 HZ
3 - 1360x768 60 HZ
4 - 1600x1200 60 Hz
5 - 1920x1080 60 HZ
6 - 1920x1200 60 HZ
7 - 3840x2160 30 HZ
8 - Auto
#SET_OUTPUT_RES 7
@OUTPUT_RES 7
#GET_OUTPUT_RES
Get the output resolution
@OUTPUT_RES 4
#GET_INPUT_RES
[PARAM]
Get the input resolution.
[PARAM]=1 ~ 4
1 - HDMI 1
2 - HDMI 2
3 - HDMI 3
4 - HDMI 4
@INPUT_RES:
1920x1080 60HZ
#SET_OUTPUT_HDCP
[PARAM]
Set the HDCP mode for output port.
[PARAM]=1 ~ 3
1 - HDCP1.4
2 - HDCP2.2
3 - OFF
#SET_OUTPUT_HDCP 1
@OUTPUT_HDCP 1
#GET_OUTPUT_HDCP
Get the HDCP mode of output port.
@OUTPUT_HDCP 1
