Seada SD-MV-CM41 - Page 5

4K 4x1 Seamless Switcher with Multi-view
Website: www.seada.co.uk 3 / 33 E-mail: sales@seada.co.uk
Max Output Level
2.0Vrms ± 0.5dB. 2V=16dB headroom above -10dBV (316 mV) nominal
consumer line level signal
THD+N
< 0.05%, 20Hz ~ 20kHz bandwidth, 1kHz sine at 0dBFS level (or max
level)
Signal-to-Noise Ratio
> 80dB, 20Hz ~ 20kHz bandwidth
Crosstalk Isolation
< -80dB, 10kHz sine at 0dBFS level (or max level before clipping)
L-R Level Deviation
< 0.05dB, 1kHz sine at 0dBFS level (or max level before clipping)
Output Load Capability
1kohm and higher (supports 10x paralleled 10kohm loads)
Noise
-80dB
Control
Control port
(1)RS232, (1)TCP/IP
Control Connector
(1) 3-pin terminal connector, (1) RJ45.
General
Operation Temperature
-5℃ ~ +55℃
Storage Temperature
-25
℃
~ +70
℃
Relative Humidity 10% ~ 90%
External Power Supply Input: AC 100~240V, 50/60Hz; Output: 24V DC 1.25A.
Power Consumption 13w(Max)
Dimension (W*H*D) 285mm x 27mm x 172.5mm
Net Weight 1.24Kg
Note: The resolution 1080i 60Hz and HDR are not supported.
