The Elite Automatic Series Vendor
INTRODUCTION
This manual is divided into three (3) main sections, Elite Snack Vendor, Money Mechanisms, and Elite Beverage Vendor. This
manual focuses on the HF3500 as it is the largest of the series, there will be points that apply only to the HF3500, and those
items will be identified for clarity.
IMPORT
ANT NOTICES
Your vendor(s) are intended for indoor use only.
Your vendor(s) must be set on a level, well -supported location.
Leave at least 10" between the left- hand side of the vendor and wall.
Leave at least 10" between the back of the vendor and wall.
Condenser cooling air is taken in the left and exhausted out the back.
Always unload vendor before transporting it.
Do not load your vendor with disfigured or damaged product.
Temperature is factory set. Allow your vendor(s) to operate for twenty-four (24) hours before attempting any adjustments.
Section 1
ELITE SNACK VENDOR
Elite Snack Vendor
HF3000
(HF2000 Not Shown)
Coin Slot and
Return Button
LED Display
Display
Window
Keypad
Front Door
Lock
Product Door
Optional
(HF3000 only)
Bill Validator
Coin Return
Door
Note: HF2000 has only
two (2) Product Trays
(Interior view with Front Door open)
Product Tray
(5 Select)
HF3000 2
HF2000 1
Product Tray
(10 Select)
Circuit Board
Bill Validator
(optional
HF3000 only)
Coin Return
Chute
Coin Validator
Coin Return
Arm
Vertical Shelf
Coin
Tray
Helix Coils
HF3000 20
HF2000 15
Vend Area
Anti-Theft Wall
