Seaga N2G5000 - REMOVING BILL VALIDATOR

EL950.1.1.1062C.4-2017
Page28
Figure22–BillValidator
REMOVINGBILLVALIDATOR
FromtimetotimeitmaybenecessarytoremovetheBillValidatorforcleaningandclearing
jams.
1. ToremovetheBillValidator
a. Disconnectthepowertothemachine–thisisveryimportanttoavoiddamaging
notonlythebillvalidatorbutyourVMC.Failuretodisconnectpowerbefore
performingthisoperationwillvoidyourwarranty.
b. UnlockandopentheFrontDoor
c. PushBillValidatorTabforwardandslideBillStorageBoxuptoremove
d. DisconnectBillValidatorfromWireHarness
e. RemovetheFour(4)MountingNuts.
Tab
BillCollection
Box
(4) Mounting
Nuts
LowerHousing
Tab
