Seaga N2G5000 - Leg Levelers; Entree Unit Bolts; Wire Harnesses

EL950.1.1.1062C.4-2017
Page8
LegLevelers
LegLevelershavebeenprovidedinyourpartspackasitisessentialforproperoperationtohave
alevelvendingmachine.Installationrequirestwopeople;onetoslightlytiltthemac hinewhile
theotherinstallsthelevelerbyscrewingitintothebaseofthemachineonallfourcorners.
Note:Careshouldbetakennottotipthevendingmachinemorethanafewdegrees.Excessive
tippingofthemachinecanruinyou rrefrigerationsystemandvoidyourwarranty.
Figure3–EntréeUnitBolts
3.) DisconnectpowerfromMainUnit.
4.) ConnectWireHarnessfromtheEntreeUnittotheMainUn
it.(Figure4)
5.) ReconnectpowertoMainUnit.
Figure4–WireHa rnesses
EntreeUnit
WireHarness
LightHarness
CoffeeEntrée
WireHarness
LightHarness
Attachwith
providedbolts
andwashers
N2G900EntréeUnit N2G5000MainUnit
