Seagate ST32151N - Figure 6 C. Mounting Configuration Dimensions for Model WC

28 Hawk 2XL Product Manual, Rev. B
Figure 6c. Mounting configuration dimensions for model “WC”
A
F
D
E
L
[1]
[3]
B
G
[1] Mounting holes three on each side, 6-32 UNC. Max 
screw length into side of drive 0.15 in. (3.81 mm).
Screw tightening torque 6.0 in-lb (.675 NM) max with
minimum thread engagement of 0.12 in. (3.05 mm).

[2] Mounting holes four on bottom, 6-32 UNC. Max 
screw length into bottom of drive 0.20 in. (5.08 mm).
Screw tightening torque 6.0 in-lb (.675 NM) max with
minimum thread engagement of 0.12 in. (3.05 mm).

[3] Power and interface connectors can extend 
past the "A" dimension by 0.040 in. (1.02 mm).

[4] Decorative front panel (optional).

[5] Connector is centered (side to side) on drive 
within ±0.020 in. (.508 mm).
Inches
A
B
C

D
E
F
G

H
J
K
L
M
N
P
R
145.80 
101.60 
25.40 

60.00 
15.75 
101.60 
6.35 

44.45 
95.25 
60.20 
25.4 
101.6 
4.83 
0.381
4.597
J
H
K
[2]
M
N
[4]
P
5.74 
4.00 
1.00 

2.362
.620
4.000
.250

1.750
3.750
2.370
1.00 
4.000
0.19 
0.015
0.181
± .010
± .010
+ .021
– .009
± .010
± .020
± .010
+ .010
– .005
± .010
± .010
± .020
± .010
± .010
± .010
max 
+ .015
– .010
± .25
± .25
+ .53
– .22
± .25
± .50
± .25
+ .25
– .12
± .25
± .25
± .50
± .25
± .25
± .25
max 
+ .38
– .25
Notes:
Dimension Table
Millimeters
C
[4]
[5]
R
Connector Centerline
Pin 1
