Seagate ST32151N - Figure 7 A. Hawk 2 XL Family Drive ID Select Header for Model N

32 Hawk 2XL Product Manual, Rev. B
Figure 7a. Hawk 2XL family drive ID select header for model “N”
[ ] Notes for Figures 7a through 7c are in Section 8.1.1.
A
2
A
1
A
0
SCSI ID = 0 (default)
Jumper Plug
(enlarged to
show detail)
J6
Drive
Front
SCSI ID = 1
SCSI ID = 2
SCSI ID = 3
SCSI ID = 4
SCSI ID = 5
SCSI ID = 6
SCSI ID = 7
L
E
D
R
E
S
R
E
S
Reserved
Pin 1
Shipped with cover installed.
Do not install jumpers; retain cover
unless 20 pin plug is installed.
1197531
Drive Activity LED
[4]
Optional connections 
to switching circuits in 
host equipment to 
establish drive ID. [4]
Dashed area is optional host circuitry (external to the drive) 
connected to host supplied optional usage plug. 
Do not connect anything to pins 13-20.
+5V
Host 
Alternate
Usage Plug:
Reserved
Pins
[3]
642
[4]
Ground
