Hawk 2XL Product Manual, Rev. B 39
Figure 8. Air flow (suggested)
Note. Air flows in the direction shown (front to back)๎
or in reverse direction (back to front)
Note. Air flows in the direction shown or๎
in reverse direction (side to side)
Above unit
Under unit
Above unit
Under unit
