34 Hawk 2XL Product Manual, Rev. B
Figure 7c. Hawk 2XL family drive ID select header J1-auxiliary for model “W” (J1-Aux. Pins 1A-12A)
SCSI ID = 8
SCSI ID = 9
SCSI ID = 10
SCSI ID = 11
SCSI ID = 12
SCSI ID = 13
SCSI ID = 14
SCSI ID = 15
A
3
A
2
A
1
SCSI ID = 0 (default)
SCSI ID = 1
SCSI ID = 2
SCSI ID = 3
SCSI ID = 4
SCSI ID = 5
SCSI ID = 6
SCSI ID = 7
A
0
J1-DC Power
68 Pin
SCSI I/O Connector
J1
J1-Auxiliary
Pin 1A
[1] [2]
Drive HDA (rear view, PCB facing downward)
[2]
Pin 1
PCB
Pin 12A
1P2P3P4P
+5V Ground
1197531
[4]
Host Alternate
Usage Plug:
Ground
8642
Optional connections to switching circuits
in host equipment to establish drive ID. [4]
Pins 2, 4, 6, and 8 are driven low for
250 ms after PWR ON and reset to
allow jumper selectable SCSI ID. [4]
Dashed area is optional host circuitry (external to the drive)
connected to host supplied optional usage plug.
[4]
+5V
N.C.
[3]
