Seagate ST32151N - Figure 11 A. Nonshielded 50 Pin SCSI Device Connector

Hawk 2XL Product Manual, Rev. B 55
Figure 11a. Nonshielded 50 pin SCSI device connector
12
3
4
.100
(2.54)
"D" ± .010
Typ.
.045
(1.14)
"C" ± .010
"B" Ref.
"A" ± .010
.834 ± .010
(21.18)
Min. Typ. 3
.051
(1.30)
.16
(4.06)
.100
(2.54)
.025
(.64)
Sq. Contact
50 Places
C
L
.040
(1.02)
Ref.
.335 ± .010
(8.50)
+.001
–.002
Dia.
.083
(2.1)
Trifurcated Pin
(4 places)
.26
(6.60)
Typ.
.065
(1.65)
x 45° Chamfer Typ.
.20
(5.08)
Typ.
.60
(15.24)
.42
(10.67)
Ref.
Insert mating cable connector here
No. Pos.

50
"A"

3.767
(95.68)
"B"

3.697
(93.90)
"C"

2.720
(69.09)
"D"

2.400
(60.96)
.037 Ref. Typ.
(.94)
.370 ± .010
(9.398)
Pin 1
