36 Hawk 2XL Product Manual, Rev. B
8.1.1 Notes for Figures 7a, 7b, 7c, 7d and 7e.
[1] Notes explaining the functions of the various jumpers on jumper header connectors J2, J1-Auxiliary and
J6 are given here and in Section 8.1.2. The term “default” means as standard OEM units are configured
with a jumper on those positions when shipped from factory. “Off” means no jumper is installed; “On”
means a jumper is installed. OFF or ON underlined is factory default condition.
[2] The PCB on “N” and “WC” model drives does not have connector J1-Auxiliary. The J1-Auxiliary connector
signals conform to SFF-8009 Revision 2.0, Unitized Connector for Cabled Drives, signal assignments for
auxiliary connectors.
[3] Reserved useage. Do not install any jumpers.
[4] Table 4 summarizes the configuration selection possibilities available on the different Hawk 2XL model
drives
[5] These signals are also on 80 pin J1 (see Table 11c)..
(“X” means the function selection can be made with jumpers on that connector;
(“Y” means the signal is available to host through that connector.)
Note. [ ] for Table 4:
[1] Use either J6 or J1-Aux, but not both.
[2] I/O connector J1 plugs directly into host. No jumper can be installed on J1. The host supplies the logic
state of these function signals; causing the selection of these functions. See pinout Table 11c.
[3] The host can drive a remotely located Drive Activity LED using signal.
[4] Use either J1 or J6, but not both.
[5] The drive reads the ID (asserted low) from J1-Auxiliary pins 1, 3, 5 and 7 for 250 ms after power-on or
drive reset. Jumper plugs can be used on J1-Auxiliary pins 1-2, 3-4, 5-6 and 7-8 to set drive ID if desired,
but usually a connector/cable is plugged to J1-Auxiliary to run these signals to the host for remote ID
selection.
[6] The drive ID signals in the 80 pin J1 connector are asserted low by the host for 250 msec after power-on
or drive reset.
Table 4: Drive configuration selections summary
ST32151/
ST31051
Model Function
Connector
Applicable
FigureJ1 J6 J1-AUX J2
N Drive ID X, Y none 7a
N Drive Activity LED Y[3] none 7a
N Option select none X 7d
W Drive ID X, Y X, Y[5] 7b, 7c[1]
W Drive Activity LED Y[3] 7b
W Option select X 7d
WC Drive ID Y[2][6] X, Y none 7b[4]
WC Drive Activity LED Y[2][3] Y[3] none 7b[4]
WC Option select:
Delayed Mtr Start Y[2] none X 7e
Enable Mtr Start Y[2] none X 7e
Write Protect none X 7e
Parity Disable none X 7e
