Seagate ST32151N - Figure 7 B. Hawk 2 XL Family Drive ID Select for Models W and WC

Hawk 2XL Product Manual, Rev. B 33
Figure 7b. Hawk 2XL family drive ID select for models “W” and “WC”
SCSI ID = 0 (default)
Jumper Plug
(enlarged to
show detail)
J6
Drive
Front
Pin 1
Reserved
A
2
A
1
A
0
[4]
[1]
Shipped with cover installed.
Do not install jumpers; retain cover
unless 20 pin plug is installed.
1197531
Drive Activity LED
[4]
Dashed area is optional host circuitry (external to the drive) 
connected to host supplied optional usage plug. 
Do not connect anything to pins 13-20.
+5V
Host 
Alternate
Usage Plug:
Reserved
Pins
6842
[4]
A
L
E
D
R
E
S
3
SCSI ID = 1
SCSI ID = 2
SCSI ID = 3
SCSI ID = 4
SCSI ID = 5
SCSI ID = 6
SCSI ID = 7
SCSI ID = 8
SCSI ID = 9
SCSI ID = 10
SCSI ID = 11
SCSI ID = 12
SCSI ID = 13
SCSI ID = 14
SCSI ID = 15
Ground
Optional connections 
to switching circuits in 
host equipment to 
establish drive ID. [4]
[3]
