Seagate ST32151N - Figure 11 C. Nonshielded 80 Pin SCSI Connector, Used on WC Model

Hawk 2XL Product Manual, Rev. B 57
Figure 11c. Nonshielded 80 pin SCSI connector, used on “WC” model
1.52
(.060)
1.32
(.052)
.097±0.10
(.038±.004)
2.70
(.106)
Section X–X
7.00
(.276)
12.70
(.500)
2.15±0.10
2 places
57.87
(2.278)
–Y–
0.15
MYM
0.15
MYM
0
–0.15
+ .000
– .006
[
[
62.15
(2.447)
± 0.15
(± .005)
Housing
X
X
Contact
0.3
(.012)
MYM
1.27
(.05)
Typ
C
L
of Datum Y
C
L
of Datum Y
0.50
(.020)
Pin 1
Pin 1
* Side View
Front View
End View
*
*
Contacts are recessed in
notches in center piece.
Top View
Back View
Insert mating
I/O connector
Grounding
Pins
Grounding
Pins
